Draw a generative locker-grid plot

Builds a grid of randomly sized, optionally subdivided rectangles with rounded corners, coloured from a supplied palette.

Usage

lockers(
  n_col = 5,
  min_rows = 5,
  max_rows = 9,
  r = 3,
  subdivide_prob = 0.2,
  min_c = 3,
  max_c = 8,
  flip = FALSE,
  col_palette = c("#413C58", "#D1495B", "#EDAE49", "#00798C", "#003D5B"),
  bg_col = "black",
  linewidth = 1,
  s = 1234
)

Arguments

n_col

Number of columns. Defaults to 5.

min_rows

Minimum number of rows per column. Defaults to 5.

max_rows

Maximum number of rows per column. Defaults to 9.

r

Corner radius in points passed to ggchicklet::geom_rrect(). Defaults to 3.

subdivide_prob

Probability that any given cell is horizontally subdivided. Defaults to 0.2.

min_c

Minimum number of subdivisions when a cell is divided. Defaults to 3.

max_c

Maximum number of subdivisions when a cell is divided. Defaults to 8.

flip

Logical. If TRUE, axes are flipped via ggplot2::coord_flip(). Defaults to FALSE.

col_palette

Character vector of colours used to build the fill palette. Defaults to c("#413C58", "#D1495B", "#EDAE49", "#00798C", "#003D5B").

bg_col

Background and border colour. Defaults to "black".

linewidth

Width of the border lines. Defaults to 1.

s

Random seed for reproducibility. Defaults to 1234.

Value

A ggplot object.

Examples

lockers()
